Locomotive Audio 14B

1-Channel Vari-Mu Compressor

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Locomotive Audio
Tubes: 1x 6BC8, 1x 12AY7 and 2x 6V6s
Input and output level variably adjustable
Attack: 300µs up to 20ms
Release: 100ms up to 2 sec
Ratio: up to 4:1 in compressor mode and up to 10:1 in limiter mode
Stereo link option
Sidechain low cut: Off or adjustable from 70 to 350 Hz
True bypass
Switch off the compression and switch to line amplifier (attack position to OFF)
VU meter for gain reduction or output level
Input stage with 2 Cinemag transmitters
Specially developed output transformer
Frequency response: 20 Hz - 20,000 Hz
THD+N: <1%
Signal-to-noise ratio (S/N): >70 dB
Connections: XLR input
XLR output and TRS jack link connection
Dimensions : 482mm x 89mm x 254mm
Weight : 8kg
Handmade in USA
