MA Lighting grandMA3 2Port Node PoE

2Port Node

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by MA Lighting
Converts network data to DMX
PoE variant (Power over Ethernet)
Synchronised output of two DMX universes
Remotely configurable via any grandMA3 console or onPC workstation
All grandMA3 xPort Nodes (with the exception of the DIN-Rail versions) are also available as onPC versions, which can be used to activate parameters for onPC workstations
MA-Net3, MANet2, sACN and Art-Net compatible
Fully RDM compatible
3.9" colour display on the front enables simple configuration and provides a quick overview
To ensure highly reliable and stable data exchange, all grandMA3 xPort Nodes are equipped with a powerful processor and a 1,000Mbit/s network interface
Parameter: None
Parameter Mode2: none
1 Power Twist TR1
1 x etherCON/RJ45
2x DMX512-A Out (5-pin XLR female)
1 x USB 2.0 (Type A)
Supply voltage: 100-240 V / 50/60 Hz / PoE (power over ethernet) (IEEE 802.3af; 48 V DC/max. 12 W)
Power: max. 15 VA
Dimensions: (W x D x H): 207 x 184 x 43 mm
Weight : approx. 2kg
