MA Lighting grandMA3 2Port Node

2Port Node

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by MA Lighting
Released in 2019
Average price : $1322
Converts network data to DMX
Synchronously outputs two DMX universes
Can be configured remotely via any grandMA3 console or an onPC workstation
All grandMA3 xPort Nodes (with the exception of the DIN-Rail versions) are also available as onPC versions, which allow activating parameters for onPC workstations
MA-Net3, MANet2, sACN and Art-Net compatible
Fully RDM compatible
3.9" Colour display on the front enables easy configuration and provides a quick overview
In order to guarantee a highly reliable and stable data exchange, all grandMA3 xPort nodes are equipped with a powerful processor and a 1,000 Mbit/s network interface
Parameter: None
Parameters Mode2: None
1x Power Twist TR1
1x etherCON/RJ45
2x DMX512-A Out (5-pin XLR female)
1x USB 2.0 (type A)
Input voltage: 100 - 240 V / 50/60 Hz
Power: Max. 15 VA
Dimensions : 207mm x 184mm x 43mm
Weight : approx. 2kg
