MA Lighting grandMA3 compact XT

Lighting Desk

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by MA Lighting
Released in 2021
Average price : $35720
Real-time control of up to 250,000 parameters per session in combination with additional grandMA3 processing units
6 DMX Outputs
1 DMX Input
2 Internal foldable monitor multi-touch screens
1 External multi-touch screen can be connected
39 Rotary RGB backlit encoders
5 Backlit dual encoders
15 Motorised and backlit 60 mm faders
60 Separate playbacks
16 Assignable x-keys
2 Backlit and motorized 100 mm A/B faders
Individually backlit and dimmable silent (clickless) keys
Parameters: 4096 (HTP/LTP)
Parameters Mode2: 8.192 (HTP/LTP)
Supply voltage: 100-240 V / 50/60 Hz
Power: Max. 300 VA
Dimensions folded (W x T x H): 845 x 429 x 160 mm
Dimensions unfolded (W x T x H): 845 x 563 x 325 (max. 410) mm
Weight : 20kg
Includes a dust cover, MA LED desk lamp, and a MA magnetic plate for the easy labelling of 15 faders
1x PowerTwist TR1
3x etherCON / RJ45
6x DMX512-A Out: 5-Pin XLR female
1x DMX512-A In: 5-Pin XLR male
1x MIDI In: 5-Pin DIN female
1x MIDI Out: 5-Pin DIN female
1x Linear timecode In: 3-Pin XLR female
1x Audio In: 3-Pin XLR female
1x GPI General Purpose Interface for remote control: D-SUB DE9 female
1x DisplayPort 1.2 for external screens
2x S / PDIF In and Out
3x USB 2.0 (Type A)
2x USB 3.0 (Type A)
1x LED desk light: 4-pin XLR female
