MA Lighting grandMA3 light CRV Demo

Showroom Model

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by MA Lighting
Real-time control of up to 250,000 parameters per session in combination with grandMA250,000 processing unit
6 DMX outputs
1 DMX input
2 Internal letterbox multi-touch screens
2 integrated multitouch command screens
4 external multi-touch screens can be connected
41 rotatable RGB-backlit encoders
5 backlit dual encoders
15 motorised and backlit 60mm faders
60 independent playbacks
16 assignable x-keys
Integrated keyboard drawer
Built-in uninterruptible power supply (UPS)
2 backlit and motorised A/B 100mm faders
Individually backlit, dimmable and low-noise (clickless) buttons
Parameter: 8.192 (HTP/LTP)
Parameter Mode2: 4.096 (HTP/LTP)
Supply voltage: 100-240 V / 50/60 Hz
Power: max. 300 VA
Dimensions : 811mm x 539mm x 169mm (closed drawer)
Weight : 25kg
1x Power Twist TR1
3x etherCON/RJ45
6x DMX512-A Out (5pin XLR female)
1x DMX512-A In (5-pin XLR male)
1x MIDI In (5-pin DIN female)
1x MIDI Out (5-pin DIN female)
1x Linear Timecode In (3-pin XLR female)
1x Audio In (3-pin XLR female)
1x GPI General Purpose Interface (D-SUB DE9 female) for remote control
4x DisplayPort 1.2 for external screens
2x S/PDIF In and Out
3x USB 2.0 (Type A)
3x USB 3.0 (Type A)
2x LED desk light (4-pin XLR female)
One dust cover
Two MA LED desk lights
MA Magnetic plate for easylabeling of 15 faders
