MA Lighting grandMA3 onPC 2Port Node DIN

Convert Ethernet data to DMX

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by MA Lighting
Released in 2022
Average price : $1817
Adds parameters to a grandMA3 onPC system
DIN rail housing for easy and time-saving mounting
Power supply via PoE (Power over Ethernet)
Two DMX outputs as 3-pin PCB connectors and directly activates 4096 parameters (= maximum for a grandMA3 onPC system)
All grandMA3 onPC xPort nodes can handle MA-Net3, MA-Net2, sACN and Art-Net data
Fully RDM compliant
3.9" Colour display on the front panel for easy configuration and status overview
Easy configuration via grandMA3 onPC software
Parameters: 4 096 (HTP/LTP)
Parameter Mode2: 1 024 (HTP/LTP)
Power supply: AC 100 - 240 V
50/60 Hz PoE (IEEE 802.3af; 48 V DC/max. 12 W)
Power consumption: max. 15 VA
Connections: 1 x Power (3pin PCB connector)
1 x Ethernet/RJ45, 2 x DMX512-A Out (3pin PCB connector), 1 x USB 2.0 (type A)
Dimensions: 150 x 50 x 90 mm
Weight : 1kg
