Manfrotto MVH500AH Fluid Head

Fluid video head with flat base

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Manfrotto
Released in 2020
Average price : $162
Built with a wider base for DSLR cameras with HD video function that moves to balance your camera
Provides smooth shooting and fine control with up to 5kg of equipment
Fluid cartridges on the pan and tilt axis to ensure that every camera movement is smooth, controlled and precise
With a side-locking system that allows the camera and slide plate to quickly snap into the head from above, rather than having to be aligned and slid in from behind
The head has a preset counterweight of 2.4 kg, but can support equipment of up to 5 kg
With an Easy Link 3/8" connector for attaching an external monitor or other accessory
The flat base mount with a standard 3/8 '' thread makes the head versatile for different support combinations (tripod, slider, boom or crane)
Top mount: 1/4" screw / 3/8" screw
Base diameter: 60 mm
Centre of gravity: 55 mm
Front tilt: -70° / + 90°
Panoramic rotation: 360°
Working height: 10,5 cm
Minimum working temperature: -20 °C
Maximum working temperature: 60 °C
Safety payload weight: 5 kg
Pan Bar included
Counterweight: 2.4 kg
Material: Aluminium
Weight : 0.9kg
Compatible accessories: 500HLV, 560BALLSH (not included)
