Moog Labyrinth

Dual Generative Analogue Synthesiser

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Moog
Dual signal path with main oscillator (sine) and modulation oscillator (triangle), each modulatable via a sequencer and envelope
Cross modulation, ring modulator and noise generator with adjustable tone colour
Wavefolder and resonant filter (low-pass / high-pass fadeable), each modulatable via a sequencer and envelope and with shared crossfader
Two regenerative sequencers with 8 steps, based on shift registers
Special functions per sequencer such as selectable tone scale, buffer freeze, adjustable length, bit shift and bit flip
Start/stop and trigger buttons, tempo control and two adjustable decay envelopes
Patchbay with 32 sockets for CV and audio signals for connection to other synthesisers or modular systems (3.5 mm jack)
Line/headphone output: 6.3 mm
Dimensions (W × H × D): 326 × 107 × 143 mm
Weight : 1.5kg
Eurorack specifications: Width: 60 HP, Depth: 38 mm
Includes power supply (12 V DC, 2.0 A), 5 patch cables, preset overlays and Quick Start Guide
