MXR Bass Preamp / EQ

Effects Pedal for Electric Bass

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by MXR
Released in 2020
Average price : $172
Bass preamp / EQ
The circuit is based on the classic Echoplex preamp
Flexible 3-band EQ with semi-parametric mid-range
Bass: +15 / -7 dB at 40 Hz
Mids: +/- 16 dB at 250 Hz to 1 kHz
Treble: +/- 10 dB at 4 kHz
True bypass
Controls for Treb, Mid, Bass, Output and FreQ
Bypass foot switch
Status LED
Metal housing
6.3 mm Mono jack input / output
Power supply via optional 9 V DC power supply (Dunlop ECB 003, 2.1 x 5.5 mm coaxial connector, polarity (-) inside)
Current consumption: 9 mA
Dimensions (L x W x H): 90 x 40 x 55 mm
Weight approx. 130 g
