One Control Black Loop - A+B Switch
A + B Switch and True Bypass Looper for Effects Pedals
Latest User Reviews
Just perfect
Build like a tank. 4 years warranty Some good routing options Ps1: Lets say that loop 1 is active and you want to turn off loop 1 and activate loop 2, in order to do that you have to press both switches at the same time. Ps2: Before you buy check the other one control switches to make sure which one suits you best. I did some reading and i watched some videos to make sure it is the right one.
Buttons are loud and not of good quality+
The sound of the buttons is pretty loud. And I got couple of times when the tip of the button got off. It isn’t really attached. So the buttons are not of best quality. The box is made of heavy metal, feels reliable. Works well as true-bypasser pedal. I use it to bypass some buffered pedals. The pedal takes one 9V power source and has output for two another. So it works as a splitter for 9V power. I found this feature useful, it helped me to organize the power supply on the pedalboard. If not buttons quality it would be really good unit.
Technical Data
- Manufactured by One Control
- Released in 2020
- Average price : $74
- The foot switches provide control over two independent send / return loops
- Can be used as a tuner output / mute switch
- 2 DC barrel connector outputs (2.1 x 5.5 mm) for looping through the power supply
- True bypass
- Loop 1 foot switch
- Loop 2 foot switch
- Status LEDs
- 6.3 mm Mono jack input / output
- 6.3 mm Mono jack send / return
- Power supply via optional 9V DC power supply (2.1 x 5.5 mm barrel connector, polarity (-) inside - not included)
- Current consumption 4 mA
- Passive operation without power supply possible (status LEDs and DC barrel connector outputs without function)
- Metal housing
- Dimensions (L x W x H): 65 x 120 x 46 mm
- Weight : 200g
