One Control Caiman Tail Loop

Loop Switcher for Effects Pedals

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by One Control
Released in 2020
Average price : $438
Programmable 5-channel true bypass loop switcher for effects pedals
Foot switches provide control over five independent loops and a separate tuner output
Extremely simple and intuitive programming
150 Freely configurable presets (30 banks, 5 presets per bank)
2 Selectable switching modes: Program Mode, Direct Mode
Integrated BJF buffer circuit with separate inputs and outputs
2 Additional connections for switching signals (amp footswitch)
5 MIDI PC and 5 CC signals can be stored in each preset
6 x DC barrel connector outputs (2.1 x 5.5 mm) for looping through the power supply
True bypass
6 Foot switches: Bank, PGM 1 / L 1, PGM 2 / L 2, PGM 3 / L 3, PGM 4 / L 4, PGM 5 / L 5, Mute / Foot Switch
Program / Direct switch
3 Button switches for programming the presets
Status LEDs
6.3 mm mono jack inputs / outputs
5-Pin MIDI input / output
Power supply via 9V DC power supply with 2.1 x 5.5 mm barrel connector, polarity (-) inside (power supply not included)
Current consumption: max. 220 mA
Metal housing
Dimensions (L x W x H): 62 x 440 x 49 mm
Weight : 620g
