One Control Minimal Series MIDI DS Loop

Technical Data

• Manufactured by One Control
• Released in 2023
• Average price : $190
• Bypass switching via MIDI
• It can use between 1-8 MIDI channels to receive control signals
• It can be controlled via program change (PC) or control change (CC) signals
• Mono and stereo signals can be processed variably
• True bypass
• Status LEDs
• Metal housing
• Input and output: 6.3 mm Mono jacks (TRS)
• Send/return: 6.3 mm Mono jack (TRS)
• 5-Pin MIDI input
• Power supply via optional 9 V DC power supply unit 2.1 x 5.5 mm hollow plug, polarity (-) inside, not included in the delivery
• Passive operation possible without power supply: Status LEDs, BJF buffer and DC hollow plug outputs then without function
• Current consumption: max. 120 mA
• Dimensions (L x W x H): 68 x 125 x 32 mm
• Weight : 366g
