RME DPS-2

Linear Power Supply for RME ADI-2 Series

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by RME
Output 1 (linear): classic DC output with multi-stage passive and active filters, 30,000 µF capacitor bank, ferrite choke and an active output filter with hybrid voltage regulator
Output 2 (µFilter) is based on the RME µFilter technology, the signal is additionally processed from the pre-filtered linear output with active filters, the output voltage is measured and regulated directly at the DC connector by means of the supplied DC special cable using a sensor
60 VA audio toroidal transformer with additional insulation winding and magnetic shielding tape for hum- and noise-free operation
Ground lift switch
Two multi-coloured front LEDs to indicate operating states and errors (existing input and output voltage, overload, undervoltage, short circuit)
Recessed push switch for AutoDark mode
Exterior dimensions (W x H x D): 130 x 52 x 205 mm
Weight : 1.89kg
DC output Linear 12 V 2.5 A
DC output µFilter 12 V 2.5 A
GND screw terminal
Input for power cable
