Rode RodeCaster Video

Technical Data

• Manufactured by Rode
• With powerful CPU, clear control panel and scene-based switching architecture for intuitive workflow for studio productions, video podcasts and live events
• Direct RTMP streaming via Ethernet or WLAN
• Direct recording (H.264) to external USB drive
• Separate ISO recording of 6 video sources plus programme feed
• 2 Downstream key and 2 chroma key controls
• Automatic standard conversion on all HDMI and USB inputs
• 2 Integrated wireless receivers for RØDE wireless transmitters
• Signal processor (Aphex): Compressor, equaliser, de-esser, stereo panorama, noise gate, high-pass filter, aural exciter, big bottom, compressor (can be set separately for each audio input and used simultaneously)
• Bluetooth 5.3 for stereo sources and phone calls
• Buttons: 7 x scene, 6 x input source, record, auto, cut, fade to black, media, overlay, multi source, keying and inspect
• High-resolution 2" touchscreen
• 2 Switching encoders: 1 x multifunction (for programming) and 1 x volume (separately adjustable for headphones 1, headphones 2 and monitors)
• 7 Scenes programmable with multi-video layers, media and graphics
• Automatic switching of sources and scenes depending on the audio signal
• Automatic chroma keying
• Power supply: USB-C (PD), 60 W (20 V / 3 A)
• Dimensions (L x W x H): 306 x 133 x 62 mm
• Weight : 1257g
• Includes 2 x WLAN antenna, power supply unit and USB-C cable
• Mic/Inst/Line inputs: 2 x XLR / 6.3 mm jack Neutrik Combo
• Video inputs (1080p): 4 x HDMI Type-A
• Multi-functional inputs (UVC): 2 x USB-C
• Monitor output L/R: 2 x 6.3 mm jack balanced
• Stereo headphone output: 2 x 6.3 mm jack
• Video outputs (1080p): 2 x HDMI Type-A
• microSD card slot for media storage (MP4, PNG/JPG, WAV)
