Showtec DB-1-4 DMX Booster / Splitter
4-Channel DMX Booster
Latest User Reviews
Does what it needs to do
Does everything you'd expect with no problems. I have had one where the LEDs died on me but it was pretty bashed about so can't blame the product.
can't go wrong
i have used this at a handful of gigs now and it has been amazing, being able to split the dmx signal to multiple different locations in a venue without having to run miles of cable. well made, it is a little bit tight in some rack cases. the only downside is i would like to be able to use both the 3 pin and 5 pin outs on the same channel at the same time.
Great DMX Splitter
We use this DMX Splitter (buffer) in a professional theatre and it suits our needs great. We have several to split out our DMX universes from the console to all the required locations and have had no issues or data loss.
DMX Booster
The Showtec 4 output splitter/booster is a great piece of kit. Well made and a study design with rack ears so it can be mounted in a 19" rack. Comes with 3 & 5 pin outputs as well as 3 & 5 pin inputs. I'm not sure whether the both 3 & 5 pin outputs can be used at the same time but at the minute that is not an issue. If you don't use 5 pin DMX cables, I recommend buying the 8 output 3 Pin splitter as it is the same price
Technical Data
- Manufactured by Showtec
- Released in 2014
- Average price : $133
- Universal optical DMX-512 splitter
- Distributes the incoming DMX signal into daisy chain configurations in four separate outputs with an additional "thru" port
- For easy connection the DB-1-4 has 3-pin and 5-pin XLR connectors
- The device can be installed into any 19" housing or via the M10 mount clamp on the back of the device
- The light controller has distinct LEDs to display the DMX signal status of each output and input
- 1x Input, 4x outputs: 3-pin and 5-pin
- An additional thru output: 3-pin and 5-pin (for connecting to other data streams)
- Electrical isolation between in- and output
- Format: 19" / 1U
- AC Power: Auto-switching 100 V - 240V 50/60Hz
- Dimensions (LxWxH): 483 x 134 x 46 mm
- Weight : 2.6kg
