Sonosax SX-M2D2

Portable 2-channel microphone preamplifier and USB audio interface

Image Sonosax SX-M2D2

Rating :

1
2
3
4
5

stars

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Latest User Reviews

3 years ago

Fantastic preamp

Nice Quality of sound with nagra7.

4 years ago

Excellent Portable Music & Mic Pre-amp!

I'm amazed by the concept in making this product. I've never come across a portable pre-amp that can be paired with your media player like Astell & kern and also as a microphone pre-amp all-in-one! But the most appealing feature for me is the ability of this pre-amp to make my Neumann D-Solution KMS-104D Digital Microphone come alive! I've been searching ways to make the 104D Microphone to work in a simple setup. Finally, my search is over! Congrats to Sonosax for making such a wonderful mini pre-amp that can serve both of my needs to listen to music and also to make recordings with my 104D & Neumann TLM-103. Exceptional!

5 years ago

great quality preamp and headphone amp

Bought it as a high quality compact field recording rig with a smartphone as a recorder. The preamp quality is super, very low noise, clean and flat response. Was very surprised by the quality of DA converter along with headphone amp when using it as an audio interfcae. Didn't expect that my Sennheiser HD650 can have such sound and that it will be so different from my other interface. But somehow sound becomes so open and detailed almost like through a pair of speakers.

Also quite handy as an interface for a laptop for online conferencing with high quality audio (with schoeps ccm41 on top)

Handling this preamp in the field is not so easy though. Requires some custom made angled mini xlr cables and adapters for audio and usb c to fit it in a custom made bag. Eventually it becomes a bit more bulky than when you look just at the preamp itself. Only two knobs for setting up also takes a bit more time than usual recorders or interface.

But still so far it's probably the best I can get on the market for such compact field recording rig with high quality

Technical Data

  • Manufactured by Sonosax
  • Released in 2020
  • Average price : $1860
  • 2 Balanced inputs for microphone and line signals
  • Per input: max. +72 dB gain
  • Switchable + 20dB pre-gain
  • Switchable phantom power: +48 V
  • Switchable high pass filter (60 - 300 Hz) and phase rotation
  • Dynamic range: 135 dB (A-weighted)
  • THD (20 Hz - 20 kHz): <0.001%
  • Frequency range: 20 - 80,000 Hz
  • Internal 6-channel mixer for analog inputs, AES inputs and USB audio
  • 2-Channel compressor / limiter with 4 memory locations
  • Free routing of all inputs and outputs for flexible adaptation to every listening and recording situation (6 user presets can be saved)
  • Integrated test tone generator
  • Class-Compiant USB 2.0 audio interface
  • 2 x 24 bit dual ADC per channel
  • Sampling rate: 44.1 kHz - 192 kHz
  • Level display of all inputs and outputs via OLED display
  • Operation via two push encoders
  • Power supply via 4-pin Hirose connector, USB C or exchangeable Li-Ion battery (3.6V, 65mm, type 18650)
  • Battery can be charged in the device via Hirose or USB power supply
  • 2 Mic / line inputs: TA-3M
  • AES input: TA-3M
  • AES output: TA-3M
  • Stereo line output: TA-3M
  • Stereo headphone output: 3.5mm TRS
  • 9-18V DC input: 4-pin Hirose
  • USB Power (USB C) and USB Audio (USB C)
  • Solid aluminium housing
  • Dimensions : 74mm x 28.5mm x 130mm
  • Weight (including battery): 336 g
  • Includes USB C cable, Li-Ion battery and transport case
