Swisson XPD-28-5R RDM & DMX-Splitter

RDM-Capable DMX Splitter and Booster

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Swisson
Released in 2019
Average price : $1426
Distributes and amplifies DMX signals from two inputs to eight outputs
This allows the 32-fixture limit of the DMX standard to be easily overcome and enables star topologies to be created.
Can also be used as a repeater to cover longer distances
Ten output modes to ensure that the relayed signals are always recognised by the connected devices
2 Failure-Behaviours
RDM-capable (bidirectional)
Optically isolated
Despite its rich feature set, the XPD-28 remains easy to operate via an encoder and eleven additional push-buttons
Signal distribution: 2x DMX/RDM in (5-pin) to 8x DMX/RDM out (5-pin).
Protocol: DMX 512 / RDM
Power supply: 110 - 240 V / 50/60 Hz
Power connection: Power Twist
Format: 19" / 1 U
Dimensions : 482mm x 111mm x 45mm
Weight : 1.7kg
