Symetrix Jupiter 8

8x8 Audio DSP Processor

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Symetrix
Released in 2020
Average price : $2316
With 8x analogue mic/line inputs and 8x analogue line outputs (implemented as terminal blocks)
Sample rate: 48 kHz
Frequency range: 20-20000 Hz +/- 0.5 dB
Dynamic range: >110 dB (A-weighted)
THD+N: <-85 dB (unweighted),1 kHz at +22 dBu with 0 dB gain
Channel separation: < -90 dB typ, at 1 kHz
Latency: <1.6 ms
Input to output
All DSP inactive
2x RJ45 ARC ports
1x RJ45 Ethernet port
4 Logic outputs
2 Control inputs (2x pot or 4x switch)
Dimensions: 48 x 195 x 4.3 cm (19"/1U)
Weight. 3.63 kg
