Synergy SYN-20IR Head

Tube Amplifier Head for Electric Guitar

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Synergy
Modular all-tube system that allows the swapping of preamp modules to expand the sound palette
Built-in American-style clean channel plus 2-channel module (not included) for a flexible 3-channel amplifier
Selectable output stage structure modes
Mode A: balanced negative feedback for a clear, powerful sound
Mode B: Vintage-style phase inverter with smooth mids and bright, shimmering highs
Mode C: Phase inverter in modern hi-fi style and low negative feedback for a modern, tight sound with full bass and muted highs
4 IR presets, individually programmable per channel - Own IRs can be loaded via the software editor
Cabless operation
Headphone output with separate volume control
MIDI-programmable (up to 128 presets)
Synergy Software Editor
Channels: 1 (3 with module)
Power: 20 W
Preamp tubes: 2 x 12AX7 (two additional 12AX7 in the module)
Output stage tubes: 2 x EL84
Controls: Volume, Tone, Reactance, Master, Headphones Level
Switches: Channel/Store, Structure/Mute, IR/Bypass
Speaker outputs 4 Ohm: 2 x 6.3 mm jack, 8 Ohm: 2 x 6.3 mm jack, 16 Ohm: 6.3 mm jack
Ultra-transparent Series effect loop-in paths: 2 x 6.3 mm jacks
Headphone output: 6.3 mm stereo jack
Balanced output: XLR
MIDI/Footswitch
USB
Dimensions : 35.6mm x 21.6mm x 19.1 cm
Weight : 16.4kg
Includes programmable 3-way MIDI footswitch, 7-pin MIDI cable and USB cable
Made in USA
