the box pro A10 LA Line Array System

Technical Data

• Manufactured by The Box Pro
• Released in 2013
• Average price : $28402
• Active Double 18" Subwoofer
• With 4" voice coil
• Class D amplifier
• Power: 2x 2000 W
• Frequency response: 36 - 100 Hz
• SPL max.: 141 dB
• 4 Presets: Standard, InfraSub, Cardioid or User
• Network connection
• XLR input and output
• PowerTwist input and output
• Dimensions: 1215 x 590 x 950 mm
• Weight : 101.68kg
• Incl. caster set
• Made in Europe
• Line Array
• Active double 10" and double 1.4" line array
• 2000 W Built-in power amp module
• XLR input and output
• Power Twist input and output
• Frequency range: 75 Hz - 20 kHz
• 110° x 10°
• Max. SPL: 131 dB
• Internal DSP with 4 presets
• Network connection via Pronet CanBus
• Dimensions : 746mm x 341mm x 530mm
• Weight : 40kg
• Made in Europe
• Flying Frame
• A 10 for LA line array elements up to 12 possible
• Dimensions 67 x 499 x 83 mm
• Weight 7.5 Kg
• CanBus Converter
• To edit the speaker DSP of A218 LA and A10 LA
• Dimensions: 150 x 110 x 60 mm
• Weight : 0.2kg
• Power Twist Link Cable 10.0 m
• Length: 10 m
• NC3FCA blue - NC3FCB blue/grey
• Rubber cable H07RN-F 3G 1.5 mm²
• Shackle
• Long version
• Designed for flying frame A10LA (# 313502)
• Stainless steel shackle with 31 mm opening
• Bolts: 16 mm
• Load-bearing capacity: 2.75 tonnes
• Breaking point: 12 tonnes
• Power Twist Link Cable
• Length: 1 m
• NC3FCA blue - NC3FCB blue / grey
• Rubber cable H07RNF 3G 1.5 mm²
• Professional Microphone Cable
• Length: 10 m
• XLR female to XLR male connectors
• Neutrik/Rean connectors
• Cable colour: Black
• Professional Patch-Cable
• 100 cm
• XLR female/male
• Neutrik (REAN) connectors
• Black
