the box pro Gala Set 804/112

Technical Data

• Manufactured by The Box Pro
• Released in 2010
• Average price : $2032
• Speaker
• Equipped with: 8 x 4" Bass & 1" BMS line driver
• Line source housing (column)
• Power rating: 300 W RMS/1200 W Peak
• Impedance: 4 Ohm
• Max. sound pressure level (SPL): 124 dB
• Frequency range: 60 Hz - 20 kHz
• Coverage pattern: 150° x 30°
• Connections: 2 x NL4 and binding posts
• Colour: Textured black
• Dimensions : 164mm x 1138mm x 233mm
• Weight : 16.7kg
• Developed in Germamy
• Amplifier with Switched-Mode Power Supply
• 2x 670 W/ 4 Ohm
• 2x 450 W/ 8 Ohm
• 2x 800 W/ 2 Ohm
• 1x 1380 W bridge at 8 Ohm
• 1x 1600 W bridge at 4 Ohm
• XLR input and output
• Speaker Twist output
• Protected circuit design: Audio limiter, temperature und short circuit
• Dimensions: 484 x 350 x 97 mm
• 19"/ 2 RU
• Weight : 10.4kg
• 12" Subwoofer
• Power rating: 350 W RMS / 1400 W peak
• Impedance: 4 Ohm
• SPL: 124 dB max
• Frequency range: 45 - 250 Hz
• Connectors: 2x SPK mounting sockets
• Stand flange M20
• Integrated crossover
• Dimensions: 450 x 380 x 456 mm
• Weight : 17kg
• Developed in Germany
• Speaker Stand
• Standard aluminium speaker stand
• Tube diameter: Ø 35 mm
• Height adjustable with clamp screw
• Additional push button for secure hold
• Extension tube diameter 35 mm
• TÜV approved up to 40 kg centric load
• Weight : 3.2kg
• Adjustable height: 1430 - 2240 mm
• Colour: Black
• Professional Speaker Cable
• Speakon Speaker Twist connector on each end
• Cross-section: 2 x 2.5 mm²
• 2-pin NEUTRIK Speakon Speaker Twist connector
• Length: 10 m
• Colour: Grey
• Not suitable for active speakers
• Not suitable for active speakers
• Professional Speaker Cable
• 2 x 2.5 mm²
• 300 cm
• Speaker Twist/ Speaker Twist
• NEUTRIK 2-pin Speaker Twist connector
• Not suitable for active speakers
• Not suitable for active speakers
• Stand Flange
• Compatible with Achat 804
