the box DSX Small Venue Set

Technical Data

• Manufactured by The Box
• Released in 2020
• Average price : $1548
• Active High Power Subwoofer
• Equipped with: 12" Speakers with 4" Voice coil
• Power: 500 W RMS, 2000 W Peak
• Peak SPL: 126 dB
• Frequency range: 45 - 150 Hz
• Stereo XLR / Jack Combo Input and XLR / Jack Combo Line Out
• M20 Threads for pole mount
• Black lacquer finish
• Dimensions: 460 x 520 x 400 mm
• Weight : 24kg
• Active Full-Range Speaker
• High-quality wooden cabinet
• 1400 W Class D power amplifier
• Contents: 10" Woofer and 1" compression driver (1.35" VC)
• Built-in DSP with 4 presets
• Low Cut
• Maximum SPL (sound pressure level): 121 dB
• Dispersion pattern: 90° x 60°
• 2 x XLR / Jack inputs
• 1 x XLR output
• Dimensions : 335mm x 545mm x 320mm
• Weight : 15.48kg
• Distance rod
• Length approx. 0.88 m to 1.36 m
• Height adjustment with safety splint
• Upper end: 35 mm
• Lower end suitable for 35 mm and M20 mountings
• Weight : 1.2kg
• Colour: Black
• Professional microphone cable
• Length: 2,5 m
• Rean XLR plug (made by Neutrik)
• XLR 3 pin male / XLR 3 pin female
• Incl. hook and loop fastener
• Colour: Black
