Warm Audio WA76-D

FET Compressor

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Warm Audio
Analogue, discrete FET compressor
Faithful reproduction of the ‘Rev D’ FET compressor with additional features
Premium O-12 input and 5002 output transformers from CineMag USA
VU metre options: Gain Reduction, +8 dB or +4 dB
Class-A line-level output amplifier
Input impedance switchable between 600 Ohm and 10 kOhm
Dry/wet control for parallel compression
Variable sidechain high-pass filter: 30 - 300 Hz, 12 dB/octave
Active bypass for operation as a line amplifier and true bypass option for A/B comparisons
Stereo link and external sidechain input
Attack: 20 µS - 0.8 mS
Release: 50 mS - 1.1 seconds
"All-Buttons-In" setting for experimental and hard limiter tones
Frequency response: ± 1 dB 20 Hz - 20.000 Hz
Signal-to-noise ratio (SNR): 86 dB
Total harmonic distortion (THD): -64 dB (at -8 dBu)
Balanced XLR and TRS inputs and outputs
Dimensions: 483 x 90 x 159 mm
Weight : 3.7kg
