API Audio ASM164
Analogue Summing Mixer
Technical Data
- Manufactured by API Audio
- 16 channels
- API 2510 Input operational amplifier
- API 2520 OpAmps
- Insert send/return on each channel
- 2 stereo programme buses: Mix-A and Mix-B
- Each channel can be assigned to Mix-A and Mix-B
- Continuously variable panning with centre detent
- 31-step, rasterised volume control
- 4-segment LED level meter
- Analogue VU meter
- Format: 19" / 2 U
- 2 line inputs: Sub-D25 (channel 1-8 and channel 9-16)
- 2 Insert Send: Sub-D25
- 2 Insert Return: Sub-D25
- 2 line inputs: XLR
- 2 line outputs Mix-A: XLR with insert Send / Return: 6.3 mm jack
- 2 line outputs Mix-B: XLR with insert Send / Return: 6.3 mm jack
