Atomos Ninja Cast

Technical Data

• Manufactured by Atomos
• Released in 2021
• Average price : $802
• Records HDR video directly from camera sensor via HDMI 2.0 in 4Kp60 with up to 10bit colour depth
• ProRes or DNxHR files can be recorded directly to affordable and fast SSDs (a 1TB SSD can hold approx. 2.5 h of 4K material)
• Bright 1000 nit 5.2" touch display
• Anti-reflective display has a dynamic range of 10 f-stops directly from log/PQ/HLG material
• Records directly from the game console via HDMI (in 4kp60 or HDp240)
• User interface offers intuitive tools for recording, control and playback (playback in increased speed, in slow motion and image for image analysis)
• 5" Capacitive touch display (IPS panel)
• Resolution: 1920 x 1080
• Aspect ratio: 16:9 native
• Inputs: 1 x HDMI with embedded audio (max. 6 channels), 1 x LANC, 2.5 mm jack, 1 x analogue audio, 3.5 mm stereo jack
• Outputs: 1 x HDMI loop-through, 1 x analogue audio, 3.5 mm stereo jack
• 1 x 2.5" SATA slot (SSD / HDD)
• Operating power: max. 19 W
• Input voltage: 6.2 to 16.8 V
• Operation via 12V-3A AC power supply or compatible NP-F series batteries (not included)
• Aluminium alloy housing with ABS polycarbonate back plate
• Mounting points: ¼-20 UNC thread, 1 x top, 1 x bottom
• Dimensions : 151mm x 91.5mm x 31mm
• Weight (without batteries & media): 360 g
• Turns Atomos Ninja into a 4-input HDMI switcher
• WebCAST - Plug-and-play UVC connection to your favourite software like Zoom, MS Teams, Skype, OBS and more
• BroadCAST - switch and record in ProRes, DNx and option for h.265
• MultiCAST: simultaneously record, stream and output to local displays
• Separate HDMI outputs - one for dedicated programme output and one multi-function output for multiview, preview or programme
• Overlay of custom graphics and logos in the lower third and picture-in-picture effect for any combination of inputs
• Passive cooling
• Inputs: 4 x HDMI type A (f)
• Outputs: 1 x HDMI type A (f) and 1 x USB-C
• Power supply: DC 6.2 - 16.8 V
• Dimensions: 16 x 12.9 x 4.9 cm
• Weight : 485g
• Ninja V
• AtomX Cast
• EVA Style Hard Case
• Neoprene Sleeve Case
• Master Caddy II Drive Caddy
• DC looking connecter
• AtomX SSD Mini Handle
• USB-C cable
