Avid Pro Tools Carbon Pre

8-Channel Preamplifier

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Avid
Released in 2022
Average price : $3645
Especially suitable as AVB extension of an existing Avid Pro Tools Carbon interface
Up to two Carbon Pre can be operated in combination with one Carbon base unit with 32 bit / 192 kHz throughout
Built-in control via Pro Tools software
Can also be used as a conventional preamp/converter combination with older Pro Tools HD systems and other interfaces.
Resolution up to 32-bit/192kHz
Word Clock In/Out
Dimensions: 19" x 1U x 343 mm
8x Combo input (XLR/jack, balanced) with variable Z (input 5-8), dynamic range: 126 dB (A-weighted), THD+N: - 105 dB (0.00056 %), frequency response: 20 Hz to 20 kHz, ± 0.1 dB, EIN: -129 dB (A-weighted)
8x Line input (25-pin D-sub, balanced), dynamic range: 125 dB (A-weighted), THD+N: -106 dB (0.0005 %), frequency response: 20 Hz to 20 kHz, ± 0.1 dB
2x Variable Z Instrument input on the front (6.3 mm jack, unbalanced), dynamic range: 125 dB (A-weighted), THD+N: -103 dB (0.0007 %), frequency response: 20 Hz to 20 kHz, ± 0.1 dB
8x Line output (25-pin D-sub, balanced), dynamic range: 120dB (A-weighted), THD+N: -110dB (0.0003%), frequency response: 20Hz - 20kHz, ±0.1dB
Pro Tools Carbon Pre
Power cable
Ethernet cable
Rack screws
Rubber feet
