Blackmagic Design Studio Camera 4K Plus G2
Broadcast Camera for Live Productions
Technical Data
- Manufactured by Blackmagic Design
- Average price : $1426
- Video, tally and remote trigger recording is transmitted to the ATEM Mini via the HDMI and SDI output
- Effective sensor size: 17.78 x 10 mm (Four Thirds)
- Lens mount: MFT bayonet with electronic aperture control
- Aperture control: Aperture, focus, zoom with supported lenses
- Dynamic range: 13 aperture stops
- Dual Native ISO at 0dB and 18dB gain
- Resolution for filming: 3840 x 2160 (Ultra HD) up to 60 fps
- Offspeed frame rates of up to 60 fps in Ultra HD
- Autofocus available when using compatible lenses
- Screen dimensions: 17.8 cm (7") with 1920 x 1200 pixels
- Screen type: LCD with Capacitive touch screen
- Screen brightness: 600 cd/m²
- Controls: Touch screen for camera settings and menus as well as setting dial, programme button, assignable function buttons F1, F2 and F3
- Rotary control for brightness, contrast and peaking
- Mounting options: 2 x 1/4" tripod thread, 1 x 3/8" tripod thread
- Storage type: 2 USBC 3.1 Gen 1 for external data carriers
- Camera dimensions: 273.6 x 169.7 x 167.3 mm
- Tripod mount dimensions: 113.7 x 35.5 mm
- Camera weight: 1380 g
- Weight of the tripod mount: 525 g
- HDMI 2.0 video outputs: 1
- SDI-In: 1
- SDI-Out: 1
- Analogue audio inputs: 1 x 3.5 mm stereo input, can also be used as a timecode input
- Analogue audio outputs: 1 x 3.5 mm mini jack for headphones
- Remote control: Camera remote control via HDMI
- Computer interface: 2 USB Type-C 3.1 Gen 1 for connection to external recording devices, focus and zoom demands and for software updates
- Built-in stereo microphone
- Built-in speaker: 1 mono speaker
- Supported codecs: Blackmagic RAW Constant Bitrate 3:1 / 5:1 / 8.1 / 12:1, Blackmagic RAW Constant Quality Q0 / Q1 / Q2 / Q3 / Q5
- Blackmagic studio camera 4K Plus G2
- Blackmagic studio camera lens hood
- Suitable tripod mount for 15 mm lightweight rails
- Module cap
- Incl. 12 V DC power supply unit
- Included software: Blackmagic camera setup software for Mac and Windows
