Manley Slam

Stereo Limiter & Microphone PreampThe slam is a combination of high-quality mic preamps and limiters with optional 192 kHz D / A and 96 kHz A / D converter. This device makes a lot of level and has a limiter that acts like a concrete wall.

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Manley
Released in 2012
Average price : $9267
Completely constructed in tube technology
Switchable 48 V phantom power and phase inversion
Transformer-balanced inputs and outputs
Gain preamp: 60 dB max .; DI: 43 dB max .; Limiter gain: 20 dB max.
Input Impedance: Preamp: 2000 ohms; DI input: 1 MOhm
FET Attack about 100uS; Release 10 ms to 2 sec; Ratio: better than 20: 1
ELOP attack approx. 10 ms for 6 dB GR; Release 2.5 Sec; Ratio: 10: 1
Frequency range: 5 to 60,000 Hz
Maximum Output: +32 dBm, +30 dBm (into 1KOhm load)
THD + N <.05% @ 1KHz Dynamic Range: 115 dB
Output impedance: 200 ohms
