RME ADI 8 QS

Technical Data

• Manufactured by RME
• Released in 2007
• Average price : $2710
• An AD-converter with a fully balanced design
• 117 dBA
• Switchable analogue and digital limiter on the AD side
• A DA-converter with a DC-coupled signal path
• Double balanced output
• 120 dBA
• Low Latency Conversion (8 samples delay)
• 16 LED level meters with 7 LEDs each
• SyncCheck
• Storage of all settings possible
• Completely remote controllable
• Digital input / output trim over a range of 6 dB per each input and output
• SyncCheck
• SteadyClock
• Expandable with an optional MADI interface
• Dimensions : 483mm x 44mm x 200mm
• Construction: 19" 1HE
• 8 x Line input and output 6.3 mm jack
• 4 x AES/EBU
• 2 x ADAT input and output
• Word clock input and output BNC
• MIDI input and output
