SPL Channel One Mk3 Premium

Channel Strip

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by SPL
Average price : $2549
Microphone inputs and output Out 1 with Lundahl transformer
1-Channel tube preamp with tube saturation, de-esser, transient designer, compressor and EQ
Discrete preamplifier with 68 dB gain
Simultaneous connection of two microphones with separately switchable 48V phantom power supply for simple A/B comparisons without reconnection
20 dB Pad
Phase inversion and high-pass filter switchable at 80 HZ
1x XLR line input with adjustable gain from -20 dB to +16 dB
1x 6.3 mm Jack instrument input adjustable from -6 dB to +30 dB
Tube saturation determines the degree of tube saturation
Tube Post option switches the Tube Saturatio after the EQ stage and before the output stage
De-esser with adjustable S-reduction
Transient Designer with attack and sustain controls for envelope editing
Compressor with adjustable threshold via compression control and make-up gain
Equaliser with semi-parametric low/mid and mid/high bands and Air Band with centre frequency at 19,000 kHz
An illuminated VU meter visualises the input level, output level and gain reduction
Two XLR outputs connected in parallel for back-up or emergency systems
1x XLR Preamp Out picks up the signal directly after pre-amplification and can be used simultaneously with Out 1 and 2
Dimensions: 482 x 88 x 210 mm
Weight : 6kg
